14 Parameter reference
14.3 Parameters of the communication module for slot MXI2
108
Lenze · E94AYCER communication module (PROFINET®) · Communication Manual · DMS 9.0 EN · 12/2013 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C14881
C14885
C14887
C14899
Parameter | Name:
C14881 | Response time when exiting "Data_Exchange"
Data type: UNSIGNED_16
Index: 9694 = 0x25DE
If the "Data_Exchange" status is exited, the response parameterised in C14880 is activated after the time set here
has expired.
• A value of "65535" in this code deactivates the monitoring function.
• A change in the monitoring response becomes immediately effective.
Setting range
(min. value | unit | max. value)
Lenze setting
0 ms 65535 0 ms
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C14885 | Clear process data
Data type: UNSIGNED_8
Index: 9690 = 0x25DA
This code is used to set the process data which the IO device is to process in order to maintain the internal
communication when the fieldbus has exited the "Data_Exchange" status.
Selection list
(Lenze setting printed in bold)
0 Use of most recent master PDOs
1 PDOs are set to the value '0'
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C14887 | Suppression diagnostic message
Data type: BITFIELD_8
Index: 9688 = 0x25D8
This code serves to inhibit the transmission of alarm messages to the IO controller. By this, errors of a specific type
can be systematically suppressed. All errors are furthermore entered in the logbook.
Value is bit-coded:
Bit 0 Fault
Bit 1 Trouble
Bit 2 Quick stop by trouble
Bit 3 Warning Locked
Bit 4 Warning
Bit 5 Reserved
Bit 6 Reserved
Bit 7 Reserved
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C14899 | Station name
Data type: VISIBLE_STRING
Index: 9676 = 0x25CC
The station name must be assigned in accordance with the PROFINET specification. In the standard setting a deleted
name is displayed. The name is also deleted if the "Reset to factory defaults" command is executed by an IO
supervisor or an IO controller.
 Setting the station name ( 35)
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
