14 Parameter reference
14.3 Parameters of the communication module for slot MXI2
106
Lenze · E94AYCER communication module (PROFINET®) · Communication Manual · DMS 9.0 EN · 12/2013 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C14867
C14879
Parameter | Name:
C14867 | Display: Most recent diagnostic data
Data type: OCTET_STRING
Index: 9708 = 0x25EC
Display of diagnostic data sent by the drive most recently:
 Diagnostic data ( 82)
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Bytes Information
0 Slot
1
2
Subslot
3
4
Error code
...
7
8
Slot
9
10
Subslot
11
12
Error code
...
15
Parameter | Name:
C14879 | Bus error
Data type: UNSIGNED_32
Index: 9696 = 0x25E0
Display of the error currently detected on the fieldbus.
Display range
(min. value | unit | max. value)
0 4294967295
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Value Meaning
0 no error
1 not used
2 not used
3 out of mem
4 add provider or consumer failed
5 miss (consumer)
6 cmi timeout
7 alarm-open failed
8 alarm-send.cnf(-)
9 alarm-ack-send.cnf(-)
10 alarm-data too long
11 alarm.ind(err)
12 rpc-client call.cnf(-)
13 ar-abort.req
