Table of attributes
Code
Name
Index
Data
Access
dec
hex
DS
DA
Data type
Factor
R
W
CINH
IP address
11575
0x2D37
E
1
UNSIGNED_32
1
Subnet mask
11574
0x2D36
E
1
UNSIGNED_32
1
Gateway address
11573
0x2D35
E
1
UNSIGNED_32
1
MAC-ID
11572
0x2D34
E
1
OCTET_STRING
Active IP Address
11565
0x2D2D
A
4
UNSIGNED_8
1
Active Subnetwork Mask
11564
0x2D2C
A
4
UNSIGNED_8
1
Active gateway address
11563
0x2D2B
A
4
UNSIGNED_8
1
All words to master
10725
0x29E5
A
32
UNSIGNED_16
1
All words from master
10724
0x29E4
A
32
UNSIGNED_16
1
All words to the basic device
10723
0x29E3
A
32
UNSIGNED_16
1
All words to the basic device
10722
0x29E2
A
32
UNSIGNED_16
1
Bus status
10714
0x29DA
E
1
UNSIGNED_16
Active station name
10711
0x29D7
E
1
VISIBLE_STRING
Display: Last safety PRM data
10710
0x29D6
E
1
OCTET_STRING
Display: Most recent diagnostic data
10708
0x29D4
E
1
OCTET_STRING
Bus error
10696
0x29C8
E
1
UNSIGNED_32
1
Monitoring Reaction
10695
0x29C7
A
1
UNSIGNED_8
1
Response time when exiting
"Data_Exchange"
10694
0x29C6
E
1
UNSIGNED_16
1
Clear process data
10690
0x29C2
E
1
UNSIGNED_8
1
Suppression diagnostic message
10688
0x29C0
E
1
BITFIELD_8
Station name
10676
0x29B4
E
1
VISIBLE_STRING
Firmware Product Type
10675
0x29B3
E
1
VISIBLE_STRING
Firmware Compilation Date
10674
0x29B2
E
1
VISIBLE_STRING
Firmware Version
10673
0x29B1
E
1
VISIBLE_STRING
I&M1 system designation
10665
0x29A9
E
1
VISIBLE_STRING
I&M1 installation site
10664
0x29A8
E
1
VISIBLE_STRING
I&M2 installation date
10663
0x29A7
E
1
VISIBLE_STRING
I&M3 additional information
10662
0x29A6
E
1
VISIBLE_STRING
I&M4 signature code
10661
0x29A5
E
1
OCTET_STRING
IP address
10575
0x294F
E
1
UNSIGNED_32
1
Subnet mask
10574
0x294E
E
1
UNSIGNED_32
1
Gateway address
10573
0x294D
E
1
UNSIGNED_32
1
MAC-ID
10572
0x294C
E
1
OCTET_STRING
Active IP Address
10565
0x2945
A
4
UNSIGNED_8
1
Active Subnetwork Mask
10564
0x2944
A
4
UNSIGNED_8
1
Active gateway address
10563
0x2943
A
4
UNSIGNED_8
1
All words to master
9725
0x25FD
A
32
UNSIGNED_16
1
All words from master
9724
0x25FC
A
32
UNSIGNED_16
1
All words to the basic device
9723
0x25FB
A
32
UNSIGNED_16
1
All words to the basic device
9722
0x25FA
A
32
UNSIGNED_16
1
Bus status
9714
0x25F2
E
1
UNSIGNED_16
Active station name
9711
0x25EF
E
1
VISIBLE_STRING
Display: Last safety PRM data
9710
0x25EE
E
1
OCTET_STRING
Display: Most recent diagnostic data
9708
0x25EC
E
1
OCTET_STRING
Bus error
9696
0x25E0
E
1
UNSIGNED_32
1
Monitoring Reaction
9695
0x25DF
A
1
UNSIGNED_8
1
Response time when exiting
"Data_Exchange"
9694
0x25DE
E
1
UNSIGNED_16
1
Clear process data
9690
0x25DA
E
1
UNSIGNED_8
1
