14 Parameter reference
14.3 Parameters of the communication module for slot MXI2
102
Lenze · E94AYCER communication module (PROFINET®) · Communication Manual · DMS 9.0 EN · 12/2013 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C14002
C14003
C14010
C14011
Parameter | Name:
C14002 | Gateway address
Data type: UNSIGNED_32
Index: 10573 = 0x294D
Setting of the gateway address
 Setting the IP configuration ( 37)
Setting range (min. value | unit | max. value) Lenze setting
0 4294967295 0
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C14003 | MAC ID
Data type: OCTET_STRING
Index: 10572 = 0x294C
Display of the MAC-ID
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C14010 | Active IP address
Data type: UNSIGNED_8
Index: 10565 = 0x2945
Display of the active IP address
The active IP address may differ from the contents of code C14000 , depending on whether the station name was
changed via the fieldbus or the parameter ( C14899 ).
Display range (min. value | unit | max. value)
0 255
Subcodes Info
C14010/1 Active IP address.1
C14010/2 Active IP address.2
C14010/3 Active IP address.3
C14010/4 Active IP address.4
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C14011 | Active subnetwork mask
Data type: UNSIGNED_8
Index: 10564 = 0x2944
Display of the active subnetwork mask
The active subnet mask may differ from the contents of code C14001 , depending on whether the station name was
changed via the fieldbus or the parameter ( C14899 ).
Display range (min. value | unit | max. value)
0 255
Subcodes Info
C14011/1 Active subnetwork mask.1
C14011/2 Active subnetwork mask.2
C14011/3 Active subnetwork mask.3
C14011/4 Active subnetwork mask.4
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
