14 Parameter reference
14.3 Parameters of the communication module for slot MXI2
104
Lenze · E94AYCER communication module (PROFINET®) · Communication Manual · DMS 9.0 EN · 12/2013 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C14852
C14853
C14861
Parameter | Name:
C14852 | All words to standard device
Data type: UNSIGNED_16
Index: 9723 = 0x25FB
Display of the process data words 1 ... 32, which are transmitted from the communication module to the drive.
Display range
(min. value | unit | max. value)
0 65535
Subcodes Info
C14852/1
...
C14852/32
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C14853 | All words from standard device
Data type: UNSIGNED_16
Index: 9722 = 0x25FA
Display of the process data words 1 ... 32, which are transmitted from the drive to the communication module.
Display range
(min. value | unit | max. value)
0 65535
Subcodes Info
C14853/1
...
C14853/32
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
Parameter | Name:
C14861 | Bus status
Data type: UNSIGNED_16
Index: 9714 = 0x25F2
Bit-coded display of current bus status
 Querying the current bus status ( 81)
Value is bit-coded:
Bit 0 Reserved
... ...
Bit 3 Reserved
Bit 4 Bit 4
Bit 5 Bit 5
Bit 6 Reserved
... ...
Bit 15 Reserved
 Read access  Write access  CINH  PLC-STOP  No transfer  PDO_MAP_RX  PDO_MAP_TX  COM  MOT
