Pin assignments

Pin assignment of the load outputs (HTS plug-in connector)

Alex M 12 x 2.5 kVA

Upper HTS plug-in connector (CH 1-6):

Pin

1

2

3

4

5

6

7

8

Assignment

(phase)

L

CH 1

L

CH 2

L

CH 3

L

CH 4

L

CH 5

L

CH 6

– –

Pin

9

10

11

12

13

14

15

16

Assignment

(neutral)

N

CH 1

N

CH 2

N

CH 3

N

CH 4

N

CH 5

N

CH 6

– –



Lower HTS plug-in connector (CH 7-12):

Pin

1

2

3

4

5

6

7

8

Assignment

(phase)

L

CH 7

L

CH 8

L

CH 9

L

CH 10

L

CH 11

L

CH 12

– –

Pin

9

10

11

12

13

14

15

16

Assignment

(neutral)

N

CH 7

N

CH 8

N

CH 9

N

CH 10

N

CH 11

N

CH 12

– –


Fig. 36:
16-pin HTS plug-in connector
(load outputs
Alex M 12 x 2.5 kVA)

N

L
