ETC Alex M Alex MX User Manual
Page 56
Technical data
Appendix
– 56 –
Alex M
030430-150B
Alex_M_E_150C_A5.doc
Selection options if DMX signal
fails
1.
Last setting
2.
One of the 12 auxiliary groups
3.
Chase
4.
All circuits dark
Surge immunity
Cold lamps can be powered up with no
restrictions.
Control curves
1.
Linear
2.
Halogen (currently not
implemented)
3. Fluorescent
lamps
4. Logarithmic
5. Non-Dim
Base load
Integrated electronic base load for
convenient dimming of fluorescent
lamps (Alex MX)
Output stages
Rated power
12 x 2.5 kVA (13 A) or
6 x 5 kVA (25 A)
Power loss
< 1% (300 W) at full load
< 2 % (600 W) at full load
90 W at no-load operation
Minimum load
Not required (0 VA) with Alex Mx
DC component at output
±1 V (control symmetrical)
cos
ϕ of the controlled load
≥ 0.4
Risetime 400
µs
