Appendix Technical data
Alex M
030430-150B
Alex_M_E_150C_A5.doc
– 57 –
General data
Mechanical design 19” rack-mountable unit as a
standalone device or for mounting in a
flight case or rack
Display LCD, 130 x 70 mm, backlit CFL,
240 x 128 pixels
Computer system Modern processor architecture based
on SMD technology
Power supply 400 V AC, 3 P + N + PE
CEE 32 A or CEE 63 A
48 to 52 Hz or 58 to 62 Hz
Power system input 5-pin CEE connector, 32 A or 63 A
Load output Multicore (Harting);
others available on request
Dimensions 19", 3 HE (132 mm),
approx. 400 mm deep without
connectors
Weight Approx. 28 kg
Cooling system Temperature-controlled fan
Housing protection class IP21
Ambient temperature Recommended: 0 to 35 °C
Permissible relative humidity 0% to 90% (non-condensing)
Safety In accordance with the European
standards EN 60204 and EN 60950
EMC In accordance with the European
standards EN 50081/82 and EN 55014
Technical data subject to change.
