14.1 3-4 95-8533
Table 3-2— Alarm Current Requirements at 24 Vdc
Device Type Number of Devices Alarm Current Total Current for Device Type
EQP Controller X 0.430 =
EQ3LTM Module X 0.001 =
EDIO 8 Inputs X 0.130 =
EDIO 8 Outputs X 0.075 =
DCIO 8 Inputs X 0.130 =
DCIO 8 Outputs X 0.075 =
Relay Module X 0.120 =
Power Supply Monitor X 0.060 =
IDC/IDCGF/IDCSC X 0.090 =
X3301/X3301A - w/o heater X 0.160 =
X3301/X3301A - with heater X 0.565 =
X3302 - without heater X 0.160 =
X3302 - with heater X 0.565 =
X2200 X 0.135 =
X9800 - without heater X 0.085 =
X9800 - with heater X 0.420 =
X5200 - without heater X 0.155 =
X5200 - with heater X 0.490 =
DCUEX X 0.160 =
DCU with EC Sensor X 0.075 =
DCU with PointWatch X 0.320 =
DCU with DuctWatch X 0.320 =
Analog Input Module X 0.300 =
Intelligent Protection Module X 0.150 =
EQ2220GFM X 0.018 =
PIRECL X 0.275 =
OPECL Transmitter X 0.220 =
OPECL Receiver X 0.220 =
ARM X 0.120 =
SAM X 0.120 =
Network Extender X 0.090 =
ASH Module X 0.560 =
EQ21xxPS Power Supply X 0.350 =
Other X =
Total Solenoid Load +
Total Signaling Load +
Total Alarm Current for System (in amperes) =
Note: This table is for battery calculations only.
