3-3 14.1 95-8533
Determining Power Requirements
Tables 3-1 and 3-2 are provided for calculating the
total current requirements for those parts of the
system requiring battery backup.
Table 3–1— Standby Current Requirements at 24 vdc
Note: Standby current is the average current draw for the device in normal mode.
This table is for battery calculations only.
Device Type Number of Devices Standby Current Total Current for Device Type
EQP Controller X 0.360 =
EQ3LTM Module X 0.001 =
EDIO Module X 0.075 =
DCIO Module X 0.075 =
Power Supply. Monitor X 0.060 =
IDC/IDCGF/IDCSC X 0.055 =
X3301/X3301A - w/o heater X 0.160 =
X3301/X3301A - with heater X 0.565 =
X3302 - without heater X 0.160 =
X3302 - with heater X 0.565 =
X2200 X 0.135 =
X9800 - without heater X 0.085 =
X9800 - with heater X 0.420 =
X5200 - without heater X 0.155 =
X5200 - with heater X 0.490 =
DCUEX X 0.145 =
DCU with EC Sensor X 0.060 =
DCU with PointWatch X 0.300 =
DCU with DuctWatch X 0.300 =
Relay Module X 0.120 =
Analog Input Module X 0.160 =
Intelligent Protection Module X 0.075 =
EQ2220GFM X 0.018 =
PIRECL X 0.270 =
OPECL Transmitter X 0.220 =
OPECL Receiver X 0.220 =
ARM X 0.075 =
SAM X 0.060 =
Network Extender X 0.090 =
ASH Module X 0.560 =
EQ21xxPS Power Supply X 0.350 =
Other X =
Total Standby Current for System (in amperes) =
