84 DS851F2
CS42L56
Notes:
1. The step size may deviate from 1.0 dB. Refer to
Figure 39 on page 89 and Figure 40 on page 89 .
2. See section “Analog Output Attenuation Characteristics” on page 26 for actual Mute Attenuation.
6.37 Limiter Min/Max Thresholds (Address 2Ch)
6.37.1 Limiter Maximum Threshold
Sets the maximum level, below full scale, at which to limit and attenuate the output signal at the attack
rate (LIMARATE -
“Limiter Release Rate” on page 86 ).
Note: Bass, Treble and digital gain settings that boost the signal beyond the maximum threshold may
trigger an attack.
6.37.2 Limiter Cushion Threshold
Sets the minimum level at which to disengage the Limiter’s attenuation at the release rate (LIMRRATE -
“Limiter Release Rate” on page 86 ) until levels lie between the LMAX and CUSH thresholds.
Note: This setting is usually set slightly below the LMAX threshold.
7 6 5 4 3 2 1 0
LMAX2 LMAX1 LMAX0 CUSH2 CUSH1 CUSH0 Reserved Reserved
LMAX[2:0] Threshold Setting
000 0 dB
001 -3 dB
010 -6 dB
011 -9 dB
100 -12 dB
101 -18 dB
110 -24 dB
111 -30 dB
Application: “Limiter” on page 46
CUSH[2:0] Threshold Setting
000 0 dB
001 -3 dB
010 -6 dB
011 -9 dB
100 -12 dB
101 -18 dB
110 -24 dB
111 -30 dB
Application: “Limiter” on page 46
