5. REGISTER QUICK REFERENCE
Default values are shown below the bit names . Unless otherwise specified, all “Reserved” bits must maintain their
default value.
Adr. Function 7 6 5 4 3 2 1 0
01h ID 1
(Read Only) DEVID7 DEVID6 DEVID5 DEVID4 DEVID3 DEVID2 DEVID1 DEVID0
p 58 x x x x x x x x
02h ID 2
(Read Only) Reserved Reserved Reserved AREVID2 AREVID1 AREVID0 MTLREVID1 MTLREVID0
p 58 x x x x x x x x
03h Power Ctl 1 Reserved Reserved PDN_VBUF PDN_BIAS PDN_CHRG PDN_ADCB PDN_ADCA PDN
p 58 1 1 1 1 1 1 1 1
04h Power Ctl 2 PDN_HPB1 PDN_HPB0 PDN_HPA1 PDN_HPA0 PDN_LINB1 PDN_LINB0 PDN_LINA1 PDN_LINA0
p 59 1 1 1 1 1 1 1 1
05h Clocking Ctl 1 Reserved M/S INV_SCLK SCK=MCK1 SCK=MCK0 MKPREDIV MCLKDIV2 MCLKDIS
p 60 0 0 0 0 0 0 0 0
06h Clocking Ctl 2 Reserved Reserved AUTO RATIO4 RATIO3 RATIO2 RATIO1 RATIO0
p 61 0 0 0 0 1 0 1 1
07h Serial Format Reserved Reserved Reserved Reserved DIF Reserved Reserved Reserved
p 62 0 0 0 0 0 0 0 0
08h Class H Ctl ADPTPWR1 ADPTPWR0 Reserved Reserved CHGFREQ3 CHGFREQ2 CHGFREQ1 CHGFREQ0
p 63 0 0 0 0 0 1 0 1
09h Misc. Ctl DIGMUX Reserved Reserved ANLGSFT ANLGZC DIGSFT Reserved FREEZE
p 63 0 0 0 0 1 1 0 0
0Ah Status
(Read Only) HPDETECT SPCLKERR DSPBOVFL DSPAOVFL MIXBOVFL MIXAOVFL ADCBOVFL ADCAOVFL
p 65 0 0 0 0 0 0 0 0
0Bh Playback Ctl PDN_DSP DEEMPH Reserved PLYBCKB=A INV_PCMB INV_PCMA Reserved Reserved
p 66 0 0 0 0 0 0 0 0
0Ch DSP Mute Ctl AMIXBMUTE AMIXAMUTE PMIXBMUTE PMIXAMUTE Reserved Reserved MSTBMUTE MSTAMUTE
p 67 1 1 0 0 0 0 0 0
0Dh ADCMIXA Vol AMIXAVOL7 AMIXAVOL6 AMIXAVOL5 AMIXAVOL4 AMIXAVOL3 AMIXAVOL2 AMIXAVOL1 AMIXAVOL0
p 67 0 0 0 0 0 0 0 0
0Eh ADCMIXB Vol AMIXBVOL7 AMIXBVOL6 AMIXBVOL5 AMIXBVOL4 AMIXBVOL3 AMIXBVOL2 AMIXBVOL1 AMIXBVOL0
p 67 0 0 0 0 0 0 0 0
0Fh PCMMIXA Vol PMIXAVOL7 PMIXAVOL6 PMIXAVOL5 PMIXAVOL4 PMIXAVOL3 PMIXAVOL2 PMIXAVOL1 PMIXAVOL0
p 68 0 0 0 0 0 0 0 0
10h PCMMIXB Vol PMIXBVOL7 PMIXBVOL6 PMIXBVOL5 PMIXBVOL4 PMIXBVOL3 PMIXBVOL2 PMIXBVOL1 PMIXBVOL0
p 68 0 0 0 0 0 0 0 0
11h Analog Input
Advisory Vol AINADV7 AINADV6 AINADV5 AINADV4 AINADV3 AINADV2 AINADV1 AINADV0
p 69 0 0 0 0 0 0 0 0
12h Digital Input
Advisory Vol DINADV7 DINADV6 DINADV5 DINADV4 DINADV3 DINADV2 DINADV1 DINADV0
p 69 0 0 0 0 0 0 0 0
13h Master A Vol MSTAVOL7 MSTAVOL6 MSTAVOL5 MSTAVOL4 MSTAVOL3 MSTAVOL2 MSTAVOL1 MSTAVOL0
p 70 0 0 0 0 0 0 0 0
14h Master B Vol MSTBVOL7 MSTBVOL6 MSTBVOL5 MSTBVOL4 MSTBVOL3 MSTBVOL2 MSTBVOL1 MSTBVOL0
p 70 0 0 0 0 0 0 0 0
15h BEEP Freq,
On Time FREQ3 FREQ2 FREQ1 FREQ0 ONTIME3 ONTIME2 ONTIME1 ONTIME0
p 70 0 0 0 0 0 0 0 0
16h BEEP Vol,
Off Time OFFTIME2 OFFTIME1 OFFTIME0 BPVOL4 BPVOL3 BPVOL2 BPVOL1 BPVOL0
p 71 0 0 0 0 0 0 0 0
17h BEEP,
Tone Cfg. BEEP1 BEEP0 Reserved TREB_CF1 TREB_CF0 BASS_CF1 BASS_CF0 TC_EN
p 72 0 0 0 0 0 0 0 0
18h Tone Ctl TREB3 TREB2 TREB1 TREB0 BASS3 BASS2 BASS1 BASS0
p 73 1 0 0 0 1 0 0 0
19h Channel Mixer
& Swap PCMBSWP1 PCMBSWP0 PCMASWP1 PCMASWP0 ADCBSWP1 ADCBSWP0 ADCASWP1 ADCASWP0
p 74 0 0 0 0 0 0 0 0
1Ah AIN Ref Con-
fig, ADC MUX AIN2B_REF AIN2A_REF AIN1B_REF AIN1A_REF ADCBMUX1 ADCBMUX0 ADCAMUX1 ADCAMUX0
p 74 0 0 0 0 0 0 0 0
