6. REGISTER DESCRIPTION
All registers are read/write except for the chip I.D. and revision register and the status register which are read only.
See the following bit definition tables for bit assignment information. The default state of each bit after a power-up
sequence or reset is listed in each bit description. Unless otherwise specified, all “Reserved” bits must maintain their
default value.
6.1
Device I.D. Register (Address 01h) (Read Only)
6.1.1
Device I.D. (Read Only)
Device I.D. code for the CS42L56.
6.2
Device Revision Register (Address 02h) (Read Only)
6.2.1
Alpha Revision (Read Only)
CS42L56 alpha revision level.
6.2.2
Numeric Revision (Read Only)
CS42L56 numeric revision level.
6.3
Power Control 1 (Address 03h)
6.3.1
Power Down VCM Bias Buffer
Configures the power state of the weak internal VCM buffer.
I²C Address: 1001010[R/W]
7
6
5
4
3
2
1
0
DEVID7
DEVID6
DEVID5
DEVID4
DEVID3
DEVID2
DEVID1
DEVID0
DEVID[7:0]
Part Number
01010110
CS42L56
7
6
5
4
3
2
1
0
Reserved
Reserved
Reserved
AREVID2
AREVID1
AREVID0
MTLREVID1
MTLREVID0
AREVID[2:0]
Alpha Revision Level
000
A
MTLREVID[1:0]
Metal Revision Level
00
0
7
6
5
4
3
2
1
0
Reserved
Reserved
PDN_VBUF
PDN_BIAS
PDN_CHRG
PDN_ADCB
PDN_ADCA
PDN
PDN_VBUF
Weak VCM Status
0
All weak VCM buffers for the AINx inputs that are not selected (either through ADCxMUX[1:0] or PGAx-
MUX[1:0]) are powered up. The weak VCM buffers for the AINx inputs that are selected are powered down.
1
All weak VCM buffers are powered down.
Application:
