Figure 6. hp output test configuration, Figure 7. line output test configuration, Figure 6 on – Cirrus Logic CS42L56 User Manual
Page 20: Figure 6, Figure 7, Cs42l56, Test load, Measurement device
20
DS851F2
CS42L56
Figure 6. HP Output Test Configuration
Test Load
HPOUTx
GND/AGND
C
L
0.1 µF
33
HPREF
R
L
Measurement
Device
-
+
Symbolized compo-
nent values are speci-
fied in table
Output Characteris-
tics” on page 19
Test Load
LINEOUTx
GND/AGND
C
L
LINEREF
R
L
Measurement
Device
-
+
Figure 7. Line Output Test Configuration
Symbolized compo-
nent values are speci-
fied in table
