CS42L56
1Bh
HPF Ctl
HPFB HPFRZB HPFA HPFRZA HPFB_CF1 HPFB_CF0 HPFA_CF1 HPFA_CF0
p 75 1 0 1 0 0 0 0 0
1Ch
Misc. ADC Ctl
ADCB=A PGAB=A DIGSUM1 DIGSUM0 INV_ADCB INV_ADCA ADCBMUTE ADCAMUTE
p 76 0 0 0 0 0 0 0 0
1Dh Gain & Bias
Ctl PREAMPB1 PREAMPB0 PREAMPA1 PREAMPA0 BOOSTB BOOSTA BIAS_LVL1 BIAS_LVL0
p 77 0 0 0 0 0 0 0 0
1Eh PGAA MUX,
Vol PGAAMUX1 PGAAMUX0 PGAAVOL5 PGAAVOL4 PGAAVOL3 PGAAVOL2 PGAAVOL1 PGAAVOL0
p 77 0 0 0 0 0 0 0 0
1Fh PGAB MUX,
Vol PGABMUX1 PGABMUX0 PGABVOL5 PGABVOL4 PGABVOL3 PGABVOL2 PGABVOL1 PGABVOL0
p 77 0 0 0 0 0 0 0 0
20h ADCA Attenu-
ator ADCAATT7 ADCAATT6 ADCAATT5 ADCAATT4 ADCAATT3 ADCAATT2 ADCAATT1 ADCAATT0
p 78 0 0 0 0 0 0 0 0
21h ADCB Attenu-
ator ADCBATT7 ADCBATT6 ADCBATT5 ADCBATT4 ADCBATT3 ADCBATT2 ADCBATT1 ADCBATT0
p 78 0 0 0 0 0 0 0 0
22h ALC Enable,
Attack Rate ALCB ALCA ALCARATE5 AALCRATE4 ALCARATE3 ALCARATE2 ALCARATE1 ALCARATE0
p 79 0 0 0 0 0 0 0 0
23h ALC Release
Rate ALC_ALL Reserved ALCRRATE5 ALCRRATE4 ALCRRATE3 ALCRRATE2 ALCRRATE1 ALCRRATE0
p 79 1 0 1 1 1 1 1 1
24h ALC Thresh-
olds ALCMAX2 ALCMAX1 ALCMAX0 ALCMIN2 ALCMIN1 ALCMIN0 Reserved Reserved
p 80 0 0 0 0 0 0 0 0
25h
Noise Gate Ctl
NGALL NG NGBOOST THRESH2 THRESH1 THRESH0 NGDELAY1 NGDELAY0
p 81 0 0 0 0 0 0 0 0
26h ALC, Limiter
SFT, ZC ALCASRDIS ALCAZCDIS ALCBSRDIS ALCBZCDIS LIMSRDIS Reserved Reserved Reserved
p 82 0 0 0 0 0 0 0 0
27h AMUTE, Line
& HP MUX AMUTE Reserved Reserved Reserved LINEBMUX LINEAMUX HPBMUX HPAMUX
p 83 0 0 0 0 0 0 0 0
28h Headphone A
Volume HPAMUTE HPAVOL6 HPAVOL5 HPAVOL4 HPAVOL3 HPAVOL2 HPAVOL1 HPAVOL0
p 83 0 0 0 0 0 0 0 0
29h Headphone B
Volume HPBMUTE HPBVOL6 HPBVOL5 HPBVOL4 HPBVOL3 HPBVOL2 HPBVOL1 HPBVOL0
p 83 0 0 0 0 0 0 0 0
2Ah Line A
Volume LINEAMUTE LINEAVOL6 LINEAVOL5 LINEAVOL4 LINEAVOL3 LINEAVOL2 LINEAVOL1 LINEAVOL0
p 84 0 0 0 0 0 0 0 0
2Bh Line B
Volume LINEBMUTE LINEBVOL6 LINEBVOL5 LINEBVOL4 LINEBVOL3 LINEBVOL2 LINEBVOL1 LINEBVOL0
p 84 0 0 0 0 0 0 0 0
2Ch Limit Thresh-
olds Control LMAX2 LMAX1 LMAX0 CUSH2 CUSH1 CUSH0 Reserved Reserved
p 85 0 0 0 0 0 0 0 0
2Dh Limit Ctl,
Release Rate LIMIT LIMIT_ALL LIMRRATE5 LIMRRATE4 LIMRRATE3 LIMRRATE2 LIMRRATE1 LIMRRATE0
p 86 0 1 1 1 1 1 1 1
2Eh Limiter Attack
Rate Reserved Reserved LIMARATE5 LIMARATE4 LIMARATE3 LIMARATE2 LIMARATE1 LIMARATE0
p 87 0 0 0 0 0 0 0 0
Adr. Function 7 6 5 4 3 2 1 0
