Edit mode
- 85 -
Non-linear edit mode
Setting the aspect ratio of the preview screen
The aspect ratio of the preview screen can be set.
1. Arrange the clips on the edit track ( @ 77 )
The aspect ratio is set to that of the file placed on the
edit track first.
2. Select [Edit] >> [Screen aspect ratio] >> [4:3
Normal], [16:9 Wide] or [16:9 Cinema] from the
menu.
Each aspect ratio is applied.
[4:3 Normal]
Displayed at the normal 4:3 aspect ratio.
[16:9 Wide]
Displayed at the wide 16:9 aspect ratio.
[16:9 Cinema]
Displayed at the wide 16:9 aspect ratio.
When outputting using this mode, video with a 4:3
aspect ratio and black bands inserted above and below
like a movie is created.
Note
` When the aspect ratio is different from the original data,
a black area is displayed above and below and to the
right and left of the image.
Aspect ratio of
original data
Aspect ratio set
[4:3 Normal] [16:9 Wide]
[16:9 Cinema]
4:3 Normal
16:9 Wide
16:9 Cinema
