Chapter 2: Installation
68
on an AT-CM70S Line Card
2. Connect the other end of the cable to an RS-232 port on a terminal or
a personal computer with a terminal emulation program.
3. Set the terminal or terminal emulation program to the following
defaults:
ˆ Baud rate: 115200 bps
ˆ Data bits: 8
ˆ Parity: None
ˆ Stop bits: 1
ˆ Flow control: None
Note
The settings are for a DEC VT100 or ANSI terminal, or an equivalent
terminal emulation program.
The software initializes and then the login prompt is displayed.
4. When prompted, enter a username and password.
ˆ To configure the chassis settings, enter “manager” as the
username. The default password for manager access is “friend”.
ˆ To just view the settings, enter “operator” as the username. The
default password for operator access is “operator”.
ˆ Usernames and passwords are case-sensitive.
The Main Menu is displayed, as shown in Figure 46.
Figure 46. AT-S70 Main Menu
Allied Telesis AT-CV5M01 Management Module Software
CV-5000 Chassis
Main Menu
Module Status and Configuration
Remote Module Status and Configuration
Administration
Image Download
System Configuration
Quit
