AT-CV5000 Media Converter Chassis Installation Guide
23
RESET LINE/
EXP Button
You can use the recessed RESET LINE/EXP button to reset the line cards
and/or the module currently present in the expansion slot in the rear of the
chassis.
Note
This reset button does not allow you to reset any management cards
in the chassis.
FAN-A Green The fan module in fan tray slot A is
operating normally.
OFF The fan module in fan tray slot A is
OFF, not present, or has failed.
FAN-B Green The fan module in fan tray slot B is
operating normally.
OFF The fan module in fan tray slot B is
OFF, not present, or has failed.
Table 1. Status LEDs on the LED Interface Card (Continued)
LED State Description
