SC Type Connectors
Dual SC
Connector
The fiber optic cable, as shown in Figure 75, is used to connect to the dual
SC connectors in various Converteon™ line cards.
Figure 75. Dual SC Connector Cable
Simplex SC
Connector
The fiber optic cable, as shown in Figure 76, is used to connect to the
simplex SC connectors in various Converteon™ line cards.
Figure 76. Simplex SC Connector Cable
