AT-CV5000 Media Converter Chassis Installation Guide
33
Management Connections
The AT-CV5000 chassis provides two ports to connect to the AT-S70
management software:
ˆ For local management, connect to the RS-232 terminal port on the
AT-CV5M01 Management Card or to the RS-232 console port on the
AT-CM70S line card only.
For more information, refer to “Starting a Local Management Session”
on page 67.
Note
You cannot access the AT-S70 management software through the
RS-232 port on the LED interface card.
ˆ For remote management using Telnet, connect to the 10/100Base-TX
Ethernet port.
For more information, refer to “Starting a Remote Management
Session” on page 70.
Note
When you install an AT-CM70S line card in an AT-CV5000 chassis,
you can manage it either through its RS-232 port or through the
terminal port on the AT-CV5M01 Management Card.
