Figure 38: installing the rack mount screws – Allied Telesis SwitchBlade x8106 User Manual
Page 84
Chapter 3: Installing the Chassis in an Equipment Rack
84
Figure 38. Installing the Rack Mount Screws
5. Tighten all six screws shown in Figure 39 on page 85 to secure the
chassis to the equipment rack, Allied Telesis recommends tightening
the screws to 10 inch-lbs.
Screws
Screws
