Allied Telesis SwitchBlade x8106 User Manual
Page 228
Chapter 10: Replacing Modules
228
4. Slowly pull the module out 25 mm (1 in.). Refer to Figure 155.
Figure 155. Withdrawing the AT-SBxFAN06 Fan Module 25 mm (1 in.)
from the Chassis
5. Wait ten seconds for the fans to stop.
Warning
The fan module has hazardous moving parts. Keep fingers away
from moving fan blades.
6. After the fans have stopped, slide the module from the chassis. Refer
25 mm
(1 in.)
