SwitchBlade x8106 Chassis Switch Installation Guide
47
SBx STATUS
LEDs
The SBx LINECARD STATUS LEDs display general status information
about the Ethernet line cards and controller cards. There are twelve LEDs,
numbered 1 to 12. Only LEDs 1 to 6 are used. They correspond to slots 1
to 6 in the AT-SBx8106 Chassis. LEDs 7 to 12 are not used. If the chassis
has two controller cards, the SBx Status LEDs are active on both cards.
The LEDs are defined in Table 11.
Table 11. SBx LINECARD STATUS LEDs
LEDs State Description
1 to 12
Solid Green Indicates that the Ethernet line or controller
card is operating normally.
Flashing Green Indicates that the card is booting up,
running in test mode, or loading its
configuration settings.
Solid Amber Indicates that the card is in an off-line state.
Possible causes are:
 An Ethernet line card that displays this
LED state may have encountered a
problem initializing the management
software.
 An Ethernet line card that displays this
LED state might not be able to boot up
because the controller card does not
have the appropriate load file and
needs to be updated to the most recent
release of the management software.
 A standby master controller card that
displays this LED state may have been
disabled by the active master controller
card because the cards have
incompatible versions of the
management software and were unable
to resolve the problem, possibly
because of insufficient free flash
memory.
You may remove a line or controller card
from the chassis when it is in this state.
Flashing Amber Indicates that the card is reporting a fault
condition. Use the management commands
to determine the specific problem.
