Allied Telesis SwitchBlade x8106 User Manual
Page 105
SwitchBlade x8106 Chassis Switch Installation Guide
105
Figure 60. Items Included with the AT-SBxPWRSYS1 DC Power Supply
Module
Note
Store the packaging material in a safe location. You must use the
original shipping material if you need to return the unit to Allied
Telesis.
4. With a #2 Phillips-head screwdriver, loosen the handle locking screw
on the power supply, as shown in Figure 61 on page 106.
One AT-SBxPWRSYS1 DC
Power Supply Module
Two straight power wire ring
lugs
One grounding wire ring lug
Two right angle power wire
ring lugs
