Page 24
Chapter 1: Overview
24
Figure 7. Rear View of the AT-SBx8106 Chassis
Figure 8 is an example of a fully populated chassis.
Figure 8. AT-SBx8106 Chassis with Line Cards, Controller Cards, and
Power Supplies
Ethernet Line
and Controller
Cards Slots
The chassis has slots for four Ethernet line cards and two AT-
SBx81CFC400 Controller Fabric Cards. The slot definitions are predefined
and may not be changed. Figure 9 on page 25 identifies the slots.
Grounding
Lug
AC Power
Cord Sockets
Power Supply
Interfaces
(Opto-couplers)
