Figure 144: removing the negative lead wire – Allied Telesis SwitchBlade x8106 User Manual
Page 213
SwitchBlade x8106 Chassis Switch Installation Guide
213
Figure 144. Removing the Negative Lead Wire
6. Use a #3 screwdriver to remove the positive (+) lead wire from the
terminal block. Refer to Figure 145 on page 214.
