Figure 130: connecting the positive lead wire – Allied Telesis SwitchBlade x8106 User Manual
Page 174
Chapter 7: Powering On the Chassis
174
Figure 130. Connecting the Positive Lead Wire
5. Wrap the negative lead wire clockwise around the remaining terminal
screw and secure the screw and wire to the negative terminal
connection on the terminal block with a #3 Phillips-head screwdriver,
as shown in Figure 131 on page 175. The negative terminal is on the
right.
