Chapter 1: Overview
58
Note
Given that the AT-SBxPWRSYS1 DC Power Supply is not
compatible with the AT-SBxPWRPOE1 AC Power Supply, a chassis
that contains one or more AT-SBx81GP24 PoE Line Cards should
use the AT-SBxPWRSYS1 AC Power Supply, and not the DC
module, as the system power unit.
LEDs
The LEDs on the power supply are described in Table 16.
Table 16. LEDs on the AT-SBxPWRSYS1 DC Power Supply
LED State Description
DC
IN
Solid Green The power supply is receiving DC power that is
within the normal operating range.
Off The power supply is not receiving power from the
DC power source.
DC
OUT
Solid Green The DC power that the module is providing to the
chassis components is within the normal
operating range.
Off The power supply is not generating DC power or
the power is outside the normal operating range.
Fault
Solid Amber The power supply has detected a fault condition,
such as an under-voltage, or over-temperature
condition.
Off The power supply is operating normally or is
powered off.
