1000base-t connector pinouts – Allied Telesis SwitchBlade x8106 User Manual
Page 240
Appendix A: Technical Specifications
240
Table 37 lists the port pin signals when a 10/100/1000Base-T port is
operating at 1000 Mbps.
Table 37. 1000Base-T Connector Pinouts
Pin
Pair
Signal
1
1
TX and RX+
2
1
TX and RX-
3
2
TX and RX+
4
3
TX and RX+
5
3
TX and RX-
6
2
TX and RX-
7
4
TX and RX+
8
4
TX and RX-
