SwitchBlade x8106 Chassis Switch Installation Guide
81
Figure 35. Rack Mounting Bracket Locations
Figure 36. Rack Bracket Locations for Reverse Position of Chassis
Factory Installed - Flush with Rack Rails
A B
C D E
“Dim X”
“Dim X” “Dim X” “Dim X”
F
Front panel
facing towards
the rear of the
equipment rack.
