SwitchBlade x8106 Chassis Switch Installation Guide
149
3. Use the twist tie that comes with the power supply to secure the cord to
an anchor on the chassis, as shown in Figure 101.
Figure 101. Securing the Power Cord for the AT-SBxPWRPOE1 Power
Supply to an Anchor
4. Connect the power cord to an appropriate AC power source to power
on the power supply.
5. If the chassis has two AT-SBxPWRPOE1 Power Supplies, repeat this
procedure to power on the second power supply.
Figure 102 on page 150 is an illustration of the power cords for a
chassis with four power supplies.
Anchor
