2. Lift the locking hand on the power supply. Refer to Figure 138.
Figure 138. Lifting the Locking Handle on the Power Supply
3. Carefully pull on the locking handle to slide the power supply from the
chassis. Refer to Figure 139 on page 208.
Warning
The power supply is heavy. Use both hands to hold the module as
you remove it from the chassis.
