Chapter 5: Installing the AT-SBx81CFC400 Controller and Ethernet Line Cards
118
Installing the Ethernet Line Cards
This section contains the installation procedure for the Ethernet line cards.
The illustrations in the procedure show the AT-SBx81GP24 Line Card.
The procedure is the same for all the cards.
Note
Please review “Guidelines to Handling the Controller and Line
Cards” on page 110 before performing this procedure.
This procedure requires the following tools:
#2 Phillips-head screwdriver (not provided)
#2 Phillips-head, 5 inch-lbs torque screwdriver (optional — not
provided)
To install the Ethernet line cards, perform the following procedure:
1. Choose a slot in the chassis for the Ethernet line card. The Ethernet
line cards may be installed in slots 1 to 4.
2. Remove the line card from the shipping package. If it is missing or
damaged, contact your Allied Telesis sales representative for
assistance.
Note
Store the packaging material in a safe location. You should use the
original shipping material if you need to return the unit to Allied
Telesis.
3. Carefully remove the Ethernet line card from the anti-static bag. Refer
