Chapter 1: Overview
48
eco-friendly
Button
You may use the eco-friendly button on the controller card to turn the
LEDs on or off. You may turn off the LEDs when you are not using them to
monitor the control and Ethernet line cards, to conserve electricity. When
the LEDs are off, the overall power consumption of the chassis is slightly
reduced, approximately 3 watts in a system with 240 active copper ports.
The button controls all of the port LEDs on the Ethernet line cards and
controller card, except for the CFC LED, which is always on, and the L/A
LED for the NET MGMT port. The button does not control the LEDs on the
fan module and power supply systems.
Reset Button You may use the Reset button to reset the controller card or all the cards
in the chassis. The action depends on the number of AT-SBx81CFC400
Controller Cards in the chassis and, if the chassis has two controller cards,
whether you reset the active or standby master controller card.
The possible actions are described here:
 If the chassis has only one controller card, pressing the Reset
button resets the controller card and all of the Ethernet line cards in
the chassis. You may perform this function if the chassis and line
cards are experiencing a problem.
Caution
The control and Ethernet line cards do not forward network traffic for
a minimum of two minutes while they initialize their AlliedWare Plus
Operating System and configure their parameter settings. Some
network traffic may be lost.
 If the chassis has two controller cards, pressing the Reset button
on the active master controller card resets the controller card, but
not the Ethernet line cards. The standby master controller card
immediately becomes the new active master card and the Ethernet
line cards continue to forward traffic. The reset controller card is
unavailable for about two minutes while it initializes its AlliedWare
Plus Operating System, after which it becomes the standby master
controller card in the chassis.
1 to 12
Off Indicates one of the following:
 The slot is empty.
 The LED is not used.
 The LEDs are turned off. To turn on the
LEDs, use the eco-friendly button.
Table 11. SBx LINECARD STATUS LEDs (Continued)
LEDs State Description
