Chapter 10: Replacing Modules
206
Replacing AT-SBxPWRSYS1 AC and AT-SBxPWRPOE1 Power
Supplies
This section contains the procedure for removing AT-SBxPWRSYS1 AC
and AT-SBxPWRPOE1 Power Supplies from the AT-SBx8106 Chassis.
Note
The illustrations in the following procedure show the removal of an
AT-SBxPWRSYS1 AC Power Supply from slot D. The procedure is
the same for all power supply slots.
To remove an AT-SBxPWRSYS1 AC or AT-SBxPWRPOE1 Power Supply
from the chassis, perform the following procedure:
1. Disconnect the AC power cord for the power supply from the AC
power source and the corresponding AC socket on the back panel of
the chassis. The figure in Figure 137 shows the removal of the power
cord from connector D, which corresponds to slot D on the front panel.
Figure 137. Disconnecting the AC Power Cord from the AC Socket on the
Back Panel
