Hardware Installation Guide 7
2
Steering Valve Installation
The Steering Valve Installation chapter information is provided in the following sections:
• Overview
• Steering Valve Installation
Overview
If the vehicle does not come with a factory installed steering system with a factory installed Steering Valve, the vehicle will
need to have a Steering Valve installed. If the vehicle is “Steer Ready” from the factory, this section can be skipped during the
installation. Contact the vehicle’s service provider to verify if the vehicle is “Steer Ready” prior to beginning the installation.
Note: Refer to this section only if this installation requires the installation of a Steering Valve.
High-Pressure Fluid Hazard
If the installation requires working on the hydraulic system
on the vehicle, read and understand the hydraulic sections
of the vehicle manufacturer’s operators manual before
starting the installation. Wear hand and eye protection while
performing hydraulic system maintenance. Relieve hydraulic
system pressure before servicing the hydraulic system.
Figure 2-1 Typical AutoSteer Steering Valve
