302
Firmware Version 5.4
7. Select Controller Device
Select DirectCommand from the Device drop-down menu. Select Granular Strip-Till Control from the
Device Type drop-down menu. Press
to continue.
8. Enter Controller Name
Controller name defaults to DirectStrip Till. Press
to accept, or press
to enter a new
name if desired. Press
to continue. Press
again to continue.
9. Container Setup (Equipment Setup Wizard: Container screen)
Press the desired channel button to enable or disable controller channel. A check mark will appear in the
box when the container is ready to be configured.
10. Assign Container Name
Container name defaults to “Bin 1, 2, or 3”. Press
to enter a new name if desired.
11. Assign Container Capacity
Use
to enter the container capacity. Press
to accept.
12. Enter Container Units
Use the drop-down menu to select the container units. Once container has been configured press
to continue.
Note:
Follow steps 9-12 for each control channel.
13. Enter Full Swath Width
Full Swath width defaults to a value of 30 ft. Use
to enter the full swath width of the implement.
Press
to continue.
14. Enter Application Point Offset
Use
to enter distance from hitch to application point (front to back). Press
to accept.
Note:
At this point additional functionality can be added to the implement. If no additional
functionality is being added, press
to continue.
15. Add Additional Devices (Optional)
Press OptRx Crop Sensor button to add sensor functionality. Use
to enter sensing width. Use
/
to enter number of sensors. Press
to continue.
16. Hitch Point Configuration
Press the Implement Provides a Hitch Point button to enter Hitch Point information. Use
to enter
Left or Right distance. Use drop-down menu to indicate distance to the left or right. Use
to enter
Forward or Backward distance. Press
to continue.
