298 Firmware Version 5.4
4. Select Conveyor to Calibrate
Press to continue.
5. Enter Dispense Amount
Enter the desired target amount of product to dispense (the recommended amount is 500 pounds or 250
kilograms). Press to continue.
6. Start Dispensing Product
Press the Start button to begin dispensing the product.
7. Product Dispensing
The conveyor will stop when the system perceives the target amount of product has been dispensed. The
Stop button can be pressed at any time to manually shut off the conveyor.
8. Product Dispensing Stops
On the screen shown after dispensing the display’s target amount, value can be reset and the process
started again for a larger sample size, if desired. Press to continue.
9. Enter Actual Dispense Amount
Enter the actual weight of the product dispensed. Press to continue.
10. Finish Calibration
A screen displays, stating Calibration Complete and underneath is shown the newly-calibrated conveyor
rate.
- Press to exit the calibration without saving the value.
- Press Repeat Calibration to begin the process again.
- Press to save the value and exit the calibration routine.
11. Restart spinner hydraulic circuit
Restart the spinner hydraulic circuit.
WARNING: Make sure the spinner is free of material before restarting the spinner hydraulic circuit.
12. A warning will appear when exiting the calibration wizard, instructing you to return the spinner control
hydraulic circuit to a field-ready condition.
Spreader Control: In-Field Calibration
The In-Field Conveyor Calibration procedure performs an automated routine to adjust the calibration
number for the selected spinner bin. This calibration is performed if there is a difference between the
amount of product logged as compared to what was actually applied.
1. Press Spreader Control button
To begin, press the Spreader Control button on the Map screen. The Spreader Control
screen opens. Press the In-Field Calibration button on the Spreader Control screen.
The In-Field Conveyor Rate Calibration Wizard appears.
2. Select Conveyor to Calibrate
Select the channel to calibrate, and press to continue.
1 2
25 25 700
RPM
