P
LANTING
D
OWN
F
ORCE
Hydraulic Pressure to Down Force Conversion adjusts system to accurately display changes to
hydraulic down force. This setting is row unit specific.
Force Conversions
Gauge Wheel Load Sensor is the type of gauge wheel load sensor used. This is specific to the make of
your planter.
Uplift Force is usually 0 unless planter is equipped with uplift springs to provide an upward force on row
units..
Maximum Force is used to limit the down force created by the actuator. The default is 425 lbs same as
the factory airbag.
Gauge Wheel Load Alarm sets alarm to notify operator when system goes below Minimum Gauge
Wheel Load for a set amount of time (Time Threshold).
Parallel Linkage
Pressure
Conversion
Deere Short Arm 4.5 psi/lb
Deere Long Arm 3.8 psi/lb
Kinze 3000 4.2 psi/lb
Kinze 4000 5.1 psi/lb
White 8000 4.8 psi/lb
Uplift Force
Parallel Linkage Uplift Force
Deere short arm 140 lbs
Deere long arm
8 spring design 160 lbs
2 spring design 100 lbs
Kinze 3000 140 lbs
Kinze 4000 130 lbs
White 8000 100 lbs
