299
A
PPLICATION
S
PREADER
3. Enter Actual Weight
The Accumulated Weight is shown in the top portion of the window. Press to enter the Actual
Weight, and press to continue.
4. Calibration Complete
A message appears, stating that your calibration is complete, and showing the CFR amount in cubic feet
per revolution. Press to finish.
T
ROUBLESHOOTING
D
IRECT
C
OMMAND
G
RANULAR
A
PPLICATIONS
Problem: Run screen Granular channel(s) green light spreader indicator will not turn on.
Solution:
1. Make sure ground speed is registered a value greater than zero on the display.
2. Verify a target rate greater than zero is entered into the display.
3. Check the switch status found on the Run screen under System and Input Diagnostics. As the
master switch is turned on and off, the Input Diagnostics window should change from black to
green (if they do not, then refer to the installation instructions to verify switch connections).
4. Check high current connection into the Granular Control Module.
Problem: Master switch will not turn on when the foot pedal is on.
Solution: Make sure the Master Switch Input is set to “External 2” under the Auxiliary Input
Settings.
Problem: AutoSwath turns on the booms too fast or too slow.
Solution: Check GPS offsets in the vehicle setup to verify all of the measurements are
correct.
Problem: AutoSwath feature is not shown.
Solution: The display must have the AutoSwath feature password-unlocked before the
feature is available to the operator.
Problem: AutoSwath is checked on, but the spreader will not turn on.
1. Make sure the ground speed is registering a value greater than zero on the display.
2. Make sure the applicator is inside of the field boundary.
Problem: Conveyor turns off in the middle of the pass.
Solution: Check the display firmware and module firmware to see if they are running the
latest version.
Problem: Total Applied does not match Actual Weight Applied.
Solution:
1. Make sure the shaft speed pls/rev are set correctly in the controller settings.
2. Make sure the controlling product is set to the correct units.
Problem: Rate not responding.
Solution:
1. Make sure there is a ground speed registering on the display.
2. Make sure the shaft speed pls/rev are set correctly in the controller settings.
