184 Firmware Version 5.4
Down Force is not shown when in Monitor Only
mode.
P
LANTER
O
PTIONS
S
CREEN
Press: Map button > Settings button > Down Force tab
or
Press: Advance Seed Monitoring button > Settings button > Down Force tab
Selecting Automatic Control enables
the system to control down force based on gauge
wheel sensor readings.
Selecting Manual Control enables the
operator to set the downforce as they see fit.
Set offset to target gauge wheel load as calculated by the down force system.
Setting Offset to Target
Minimum -100 lbs
Light -50 lbs
Medium (default) 0
Heavy +50 lbs
Maximum +100 lbs
2 4 6 8 10 12 14 16 18 20 22 24
400 lb
300 lb
200 lb
100 lb
Down Force 190 lb
Settings Down Force
Down Force
Planter Options
Planter Drives Seed Monitor
Status
Gauge Wheel
Down Force
Pressure
Active
Channel 1
Down Force
Channel 2
Active
Gauge Wheel Load
Channel 1
1 - Light
Channel 2
1 - Light
Gauge Wheel By Row
2
7
11
12
13
14
97.3 kg
86.2 kg
8.5 bar
86.2 kg
8.5 bar
102.0 kg
86.2 kg
82.9 kg
79.7 kg
93.4 kg
92.9 kg
Automatic
Control
Manual
Control
Automatic
Control
Manual
Control
Gauge Wheel Load
Channel 1
1 - Light
Channel 2
1 - Light
