Down Force Channel 1 and Channel 2 tabs
The pressure and duty cycle settings are to help the display control the hydraulics. The defaults should
be correct.
Hydraulic Pressure (Grayed out for Monitor Only).
Operating Limits Pressure Duty Cycle
Ag Leader Valve Block Calibration
Minimum 100 0
Medium 550 20
Maximum 2800 65
Down Force
Channel 1 General Channel 2
Hydraulic Pressure
Minimum
Medium
Maximum
Duty Cycle
Minimum
Medium
Maximum
Row Unit Sensors
Sensor 1 Sensor 2
Sensor 3 Sensor 4
Calibrate
Pressure Sensor
Pressure Sensor
Enable
0
20
65
200
PWM
Frequency
100
550
2800
