173
P
LANTING
R
ATE
C
ONTROL
7. Seed Dispensing Complete
When the meter is finished dispensing seed, the button will change back to its original green color, and will
once again display the word Start. Press
to continue.
8. Enter Number of Dispensed Seeds
Press
to enter the number of dispensed seeds. Press
to continue.
Note: The meter calibration will be calculated from the actual seed amount dispensed.
R
ATE
C
ONTROL
: M
AP
S
CREEN
The map screen displays a one row per
section SeedCommand configuration
running a Variable Rate Control
configuration that includes three
Hydraulic Seed drives, and also Row
Shutoff with AutoSwath. Because the
configuration is for a split-planting
operation with three varieties, these three
varieties are shown with different colors
on the map.
Note: The Rate buttons in the Product Control Toolbox at top right are explained in
.
P
RODUCT
C
ONTROL
T
OOLBOX
During SeedCommand Run Time operations, the Product Tabs are
shown in the upper right-hand side of the Map screen. Press the
Product Tabs, and an extended view shows the Rate buttons, Manual
Valve Control button, Prescription button, Rate increase and decrease
arrows
/
, and the Rate Setup button, all of which are
described below.
• (A) Variety
The Product Control Toolbox can show rates for multiple varieties,
depending upon the particular planting configuration. Press the area of the
box that shows a particular variety, and a green bar highlights that variety.
The Rate 1 and Rate 2 are then shown on the Rate buttons.
100%
30000
32000
38.4
ac
30000
30000
32000
32000
sds/ac
40 ft 0 in
Population: 32000 sds/ac
Spacing: 6.7 in
5.0
mph
Varieties
Corn
Flow: 5280 sds/min
1
2
92B12
S46R1
sds/ac
Planter Drives (rpm)
Settings
C1966
C1291
sds/ac
1
2
3
32
38
37
C1045
Down Force
Gauge Wheel:
197 lb
Down Force:
197 lb
CSX56B10CONV
sds/ac
40000
40000
2
4
6
8
10
12
14
16
18
20
22
24
120 %
100 %
80 %
60 %
30000
32000
sds/ac
sds/ac
30000
30000
30000
32000
Flow: 5280 sds/min
Applied: 501644.0 sds
Area: 19.17 ac
92B12
S46R1
