287
A
PPLICATION
S
PREADER
• Press Swath Offsets button to enter offsets. System can not be configured with sensors and application
point on opposite sides of the hitch.
Press to continue.
14. Enter Hitch Point Information
Enter if implement provides a rear hitch and offset measurements.
15. Self-Propeller Spreader
Enter Vehicle Name (a suggested name appears)
- If desired, press to enter a different name for your vehicle. Press when complete.
Select vehicle and press to continue.
16. Drawn Spreader
Enter Implement Name (a suggested name appears)
- If desired, press to enter a different name for your implement. Press when complete.
Select implement and press to continue.
Select Second Implement.
- Use drop-down menu to select Implement or press to add second implement.
- Press if there is no second implement.
- Press if a second implement is being used.
17. Select Speed Source
Use drop-down menu to select Primary Source, set Backup Source, and configure Auxiliary Channel.
Press Calibrate Speed Sensor to launch the Speed Sensor Calibration Wizard.
18. Enter Configuration Name
A suggested name for the configuration appears. If desired, Press to enter a different name for
your configuration. Press when complete.
The completed configuration should now appear under the Application heading located on the
Configuration tab of the Configuration Setup screen.
C
ONTROLLER
S
ETTINGS
Press: Home button > Setup (wrench) button > Configuration (tractor) button > Configuration tab > select
your specific configuration > Setup (wrench) button >Controller Settings button
Controller Settings screen appears, with each channel’s settings shown on its own tab.
The settings shown at this screen vary, depending upon whether your spreader uses a PWM Control
Valve or a Servo Control Valve. Use the Control Valve Configuration drop-down menu to choose the
appropriate configuration for your machine.
Configuration
Select Your Specific
Configuration
Controller Settings
