• Front Units and Rear Units
Use / to adjust the number of front and
rear planting units, if necessary.
• Shaft RPM Sensors
Use / to adjust the number of Shaft RPM
Sensors, if necessary.
• Row Spacing
Shows the minimum row spacing of the planter. Press
to adjust the Row Spacing.
• Seed Size Sensitivity
Changes automatically with product type selection.
• Reset
Returns settings to factory defaults, which allows operator to run Muxbus Sensor Detection again.
Ground Speed Settings
• Magnetic Pickup
Check the Magnetic Pickup check box only if the planter is equipped with the Magnetic Pickup Sensor. This
setting should then be left unchanged. For information on calibrating the Magnetic Coil Speed Sensor, see
“KINZE Magnetic Coil Speed Sensor Calibration” on page 206
Note: Customers who do not have the magnetic pickup sensor who check this box will see a window stating
“Bad Configuration: No Magnetic Pickup sensor currently found.”
• Speed Source
The Speed Source drop-down box selects the type of speed source for the planter monitor. Choose
between GPS, AUX (Auxiliary Input Module) and PMM.
Note: This speed selection only affects the PMM. The ground speed source must still be selected.
Other Sensors
Other check boxes on the Planter Configuration window include:
• Down Pressure
Check this box if the planter has pneumatic down pressure.
• Oil Sensor
Leave this box unchecked.
• SDS Sensors
Leave this box unchecked.
• Air Compressor
Check this box if the planter has an air compressor installed.
• Tank Weight
Check this box if the planter has a tank weight sensor install.
30 in
Magnetic
Pickup
Shaft RPM
Sensors
Planter Configuration
