System Specifications
Hardware Specifications
C-4
User Interface • 2x20 LCD with back light for initial
system configuration and status/
error monitoring
• Four pushbutton switch interface
• Front panel controls for on front
panel for:
• Network configuration: IP address,
gateway IP, and subnet mask
• System operation: initiating system
shutdown or reboot, silencing
audible alarms
• Single push-button switch interface
on front panel for silencing audible
alarm
Disk Drive Interface Wide Ultra2 SCSI, SCA connector
Minimum Raw Storage Capacity
(RAID 5) 72GB (3x36GB drives, RAID5,
additional hot spare can be added)
Maximum Raw Storage Capacity
(RAID 5) Up to 10 Ultra2 SCSI disks
• 288GB (10x36GB drives)
a
Maximum RAID5 Group Size Up to 8 drives per RAID5 group
Available Network Interfaces • Supported by add in PCI card
• Vendors/Cards supported
• 10/100TX
• Half or full duplex
• RJ-45 connector
• Dual 10/100TX
• Half or full duplex
• RJ-45 connector
• Gigabit Ethernet
• Half or full duplex
• 1000BASE-SX (fiber)
External Tape Backup Device
Support • Supported by included PCI card
• Wide SCSI 68 pin connector
a. Disks configured as two RAID5 groups of 5 drives each, no hot
spare available.
