Component Identification

HP StorageWorks Modular Smart Array 500 System User Guide

1-17



Hot-Plug SCSI Hard Drive LED Combinations

Table 1-12: Hot-Plug SCSI Hard Drive LED Combinations

Activity
LED

Online
LED

Fault
LED

Status

On Flashing

Off Do not remove the drive. Removing a drive during this

process can cause data loss in non-fault-tolerant
configurations.

The drive is a replacement drive and is being rebuilt or

If all online LEDs in a drive array are flashing, an
expansion is occurring.

Off

Off

On

OK to replace the drive online.

The drive has failed and has been placed offline.

Off, on, or
flashing

On Off Do not remove the drive. Removing a drive during this

process can cause data loss in non-fault-tolerant
configurations.

The drive is online and configured as part of an array.

Off, on, or
flashing

On or Off

Flashing

A predictive failure alert has been received for this drive.
Replace the drive as soon as possible.
