Component Identification

HP StorageWorks Modular Smart Array 500 System User Guide

1-9



4-Port Shared Storage Module Components

2

1

4

3

Table 1-6: 4-Port Shared Storage Module Components

Item Description

Bus

1

SCSI port connector A1

2

SCSI port connector A2

A

3

SCSI port connector B1

4

SCSI port connector B2

B
