Web Tools User’s Guide 4-13
Switch View
4
Thresholds for the Remaining Classes
The Port, E_Port, F/FL Copper Port, F/FL Optical Port classes display the following fields for each
area (Link Loss, Sync Loss, Signal Loss, Protocol Error, Invalid Words, Invalid CRCs, State
Changes, RX Performance, TX Performance):
The thresholds for the Port class are displayed as shown in Figure 4-10:
Figure 4-10 The Configure Threshold tab with the Port class selected in Fabric Watch
View
Low text box Enter the low thresh boundary.
High text box Enter the high thresh boundary.
Threshold Type drop-down
list Select the type of threshold.
Time period drop-down list Select the time period for which you want a time-based count
to be measured.
