4-58 Web Tools User’s Guide
Switch View
4
Port Settings Tab
Use the Port Settings tab to disable/enable ports on the switch. This tab is also used to set port
speed to 1GB/2GB Autosense as well as enable/disable Trunking. The Port Settings tab is shown in
Figure 4-12.
Figure 4-12 Port Settings Tab
OK Click to save the changes made to the tab and to exit the tab.
Apply Click to save the changes made to this tab and to stay in the current tab.
Additional changes can be made and the APPLY button pressed when
making changes incrementally.
Close Click to exit the current tab. If changes have been made but not
committed by clicking the APPLY button, a dialog box displays.
Reset Click to reset the tab to the last set of committed changes. If the
APPLY button has not been pressed on this tab, the parameters are
returned to the original values the tab had when it was initially
displayed.
